基本結構

Basic structure

(1)注塑模具的機構和參數是否與注塑機相匹配。

(1) Whether the mechanism and parameters of the injection mold match the injection molding machine.

(2)注塑模具是否有合模導向機構，機構設計是否合理。

(2) Whether the injection mold has a clamping guide mechanism, and whether the mechanism design is reasonable.

(3)分型麵的選擇是否合理，是否有飛邊的可能，塑件是否卡在頂出機構中設置的動模（或定模）的一側。

(3) Whether the selection of parting surface is reasonable, whether there is possibility of flash, and whether the plastic part is stuck on one side of the moving die (or fixed die) set in the ejection mechanism.

(4)型腔的布置和澆注係統的設計是否合理。澆口與塑料原料是否相容，澆口位置是否對等，澆口和流道的幾何形狀和尺寸是否合適，流量比是否合理。

(4) Whether the layout of the mold cavity and the design of the gating system are reasonable. Whether the gate is compatible with plastic raw materials, whether the gate position is equal, whether the geometry and size of gate and runner are appropriate, and whether the flow ratio is reasonable.

(5)成型件的設計是否合理。

(5) Whether the design of molded parts is reasonable.

(6)彈射彈射機構和側陽型。或者抽芯機構是否合理、、可靠、有無幹擾和遮擋。

(6) Ejection ejection mechanism and side male type. Or whether the core pulling mechanism is reasonable, safe, reliable, with or without interference and shielding.

(7)是否有排氣機構，其形式是否合理。

(7) Whether there is an exhaust mechanism and whether its form is reasonable.

(8)是否需要溫度調節係統。其熱源和冷卻方式是否合理。

(8) Whether a temperature regulating system is required. Whether the heat source and cooling mode are reasonable.

(9)支撐部件的結構是否合理。

(9) Whether the structure of supporting parts is reasonable.

(10)外形尺寸能否保證安裝，固定方式的選擇是否合理可靠，安裝螺栓孔與注射機構和定模固定板上的螺孔位置是否一致.

(10) Whether the overall dimension can ensure installation, whether the selection of fixing method is reasonable and reliable, and whether the position of mounting bolt hole is consistent with that of screw hole on injection mechanism and fixed mold fixing plate

設計圖紙

Design drawings

(1)裝配圖。零部件的裝配關係是否清晰，匹配代號是否正確合理標注，零部件標注是否齊全，是否與明細表中的序號對應，相關描述是否標注清楚，整個注塑模具的標準化程度如何。

(1) Assembly drawings. Whether the assembly relationship of parts and components is clear, whether the matching code is correctly and reasonably marked, whether the marking of parts and components is complete, whether it corresponds to the serial number in the list, whether the relevant description is clearly marked, and how standardized the whole injection mold is.

(2)零件圖。零件編號、名稱、加工數量是否標注準確，尺寸公差及各種公差是否合理、齊全，成型件易磨損部位是否有預留磨削量，哪些零件具有超高精度要求，以及這樣的要求是否合理，每個零件的材料墊是否合適，熱處理要求和表麵粗糙度要求是否合理。

(2) Part drawings. Whether the part number, name and processing quantity are correctly marked, whether the dimensional tolerance and various tolerances are reasonable and complete, whether there is reserved grinding amount for the easily worn parts of the formed parts, which parts have ultra-high precision requirements, and whether such requirements are reasonable, whether the material pad of each part is appropriate, and whether the heat treatment requirements and surface roughness requirements are reasonable.

(3)繪圖方法。濟南注塑模具技術人員認為其繪圖方法是否正確，是否符合標準，表麵表達的幾何圖形和技術要求是否易於理解。

(3) Drawing method. Jinan injection mold technicians think whether the drawing method is correct, whether it conforms to the national standards, and whether the geometric figures and technical requirements expressed on the surface are easy to understand.

注塑模具的審核包含兩個內容，在這裏講解了基本結構以及設計圖紙兩個方麵，您可以關注我們網站www.lsjtcyjt.cn了解更多相關資訊！

The review of injection mold includes two parts. Here we explain the basic structure and design drawings. You can follow our website for more information!
