一、模料：
1.
1.凡長a、寬b均≥200mm鋼料〈線切割模芯料後續需求淬火處理模料除外〉，統肯定購精料。
1. For all steel materials with length a and width b ≥ 200mm (except for wire cutting die core materials requiring subsequent quenching treatment), we are willing to order refined materials.
(1)精料尺寸：axbxh粗料尺寸：axbxh
(1) Fine material size: axbxh coarse material size: axbxh
(2)加硬料訂購精料時單邊加大0.75mm，高度加高1mm.。
(2) When adding hard materials and ordering fine materials, the single side shall be increased by 0.75mm and the height shall be increased by 1mm.
(3)行位料統一訂購粗料。
(3) Coarse materials are ordered uniformly for row level materials.
(4)嗬料鑲件統一訂購粗料，多個小鑲件可拚合訂購一件整料，留出適當的線割位，並做出適當的線割排位圖。
(4) The coarse materials shall be uniformly ordered for material inserts, and multiple small inserts can be assembled to order a whole material, leaving appropriate line cutting position, and making appropriate line cutting arrangement diagram.
2.耐磨塊遵從本質設計尺寸單邊加大2mm，訂購粗料。
2. The wear-resistant block shall comply with the essential design, the size shall be increased by 2mm on one side, and the coarse material shall be ordered.
3.多個直徑小於Ф40mm(含)的圓材可拚合定購長件料。同時在總長度上加上車床裝夾尺寸和鋸床消耗尺寸15MM。單件>Ф40mm的圓材定購尺寸為設計長度加上15mm，ф110(含)下麵的圓料所以5進製的，ф120(含)以上以10進製。撐頭遵從本質尺寸訂購，要求加工見白能夠，全部圓料均訂購粗料。
3. Multiple diameters less than Ф Round timber of 40mm (included) can be assembled to order long pieces. At the same time, add the lathe clamping size and sawing machine consumption size of 15mm to the total length. Single piece > Ф The order size of 40mm round timber is the design length plus 15mm, ф The round material below 110 (including) is so 5-ary, ф Above 120 (inclusive) in decimal system. The support head shall be ordered according to the essential size. It is required that the processing can be seen in white, and all round materials shall be ordered as coarse materials.
4.線割模料訂購尺寸(a+10x(b+5)x(c+5)。
4. Order size of wire cutting die material (a + 10x (B + 5) x (c + 5).
(當中10為線切割時裝夾所需尺寸，a、b辭別是零件設計尺寸。)
(among them, 10 is the required size of wire cutting fashion clip, and a and B are the design size of parts.)
5.後續需淬火處理的模料，定購尺寸(a+5)X(b+5)X(h+2)
5. For the subsequent die materials to be quenched, the order size is (a + 5) x (B + 5) x (H + 2)
(當中a、b、h為零件設計尺寸，5mm為熱處理變形分量。)也可視材質來定,肯定其變形量大小適當增添尺寸,通常狀況下不少於5MM.
(among them, a, B and H are the design dimensions of parts, and 5mm is the deformation component of heat treatment.) it can also be determined according to the material, confirm the deformation, and increase the size appropriately, usually not less than 5mm
6.斜頂訂購方式同於線割模料訂購尺寸，假如一套模中的斜頂較多，可將尺寸和形式相近的斜頂訂購在一塊料上，並適當排位，便於線割加工。
6. The inclined top ordering method is the same as the wire cutting die material ordering size. If there are many inclined tops in a set of dies, the inclined tops with similar size and form can be ordered on one piece of material and properly arranged for wire cutting processing.
二、模架
Two. Mould frame
1、模架遵從龍記準則訂購，假如客戶有指定，遵從客戶指定訂購。
1. The mold base shall be ordered in accordance with Longji guidelines. If the customer has specified, the order shall be in accordance with the customer's specified order.
2、模架開框尺寸：X、Y在300下麵的衙役為，X、Y在301以上的衙役為。深度衙役通常遵從龍記準則做，50以上的開框深度衙役為。
2. The opening dimension of formwork: for the Yamen with X and y below 300, and for the Yamen with X and Y above 301. The depth yamen usually follow the Longji standard, and the opening depth Yamen with X and Y above 50 is.
3、模胚開框圖內要注明技藝要求及個體相關方式。
3. The technical requirements and individual related methods shall be indicated in the mold opening block diagram.
三、模具配件
Three, mold accessories
1、凡選用DME和HASCO及大同準則頂針和司筒時，除在訂料單上注明其型號外另以複印方式將所指定的頂針或司筒地點頁碼複印走出，並以打勾方式注明，作為附頁一起下發，並在BOM單上注明是DME(歐洲或北美)或HASCO(歐洲)規格。
1. When DME, HASCO and Datong standard thimble and cylinder are selected, in addition to indicating the model on the purchase order, the page number of the designated thimble or cylinder locations shall be copied out in the form of copy, marked in the form of tick, distributed as an attached page, and indicated as DME (Europe or North America) or HASCO (Europe) specification on the BOM.
2、當用到非標司筒時，在訂料上注明非標外，還要注明非標字樣，並以附圖方式打印並下發。
2. When non-standard cylinders are used, non-standard words shall be indicated on the ordering materials in addition to non-standard words, which shall be printed and distributed in the form of drawings.
3、彈弓注明供應商，並寫明顏色(通常狀況下選用藍彈弓較多);水口拉針要注明型號和供應商;唧嘴多由本廠加工，隻需訂購圓料和寫明尺寸並附圖，不需注明供應商。
3. The slingshot shall be marked with the supplier and the color (usually blue Slingshot is more used); the model and supplier of the nozzle pull needle shall be marked; the pump nozzle is mostly processed by our factory, so it is only necessary to order round materials, indicate the size and attach drawings, without indicating the supplier.
